RAILING CATALOG 7th Edition
“It’s all in the view.” Our mission is to provide each customer with dedicated customer service, factory-direct prices, and low-maintenance, high-quality railing systems that stand the test of time.
Stainless Steel Round Posts
4 | 360.323.5416 | STAINLESSCABLERAILING.COM CableView® Aluminum in Black, Wood Top Rail
STAINLESSCABLERAILING.COM | 360.323.5416 | 5 STAINLESS CABLE & RAILING We are an international cable railing manufacturer and distributor based in Washougal,WA. By specializing in cable railings, we offer our customers superior products and expert advice. Each estimate is uniquely designed and our in-shop fabrication services allow us to customize our products to meet your needs. Our railing systems are defined by the craftsmanship, value, and enjoyment they provide. CRAFTSMANSHIP We build quality products made from durable, low-maintenance materials, including marine grade 316L stainless steel. Our state-of-the-art in-house fabrication ensures quality control and allows us to accommodate the specific needs of any project. VALUE As both manufacturer and retailer, we skip the middleman entirely. This allows us to offer our customers economical, factorydirect prices for premium products. Our durable systems will stand the test of time while providing dependable safety. ENJOYMENT With clean lines and an open design, our railings are built to be enjoyed. Our team of railing experts are at the ready to help you achieve that perfect, final railing as quickly and smoothly as possible through one-on-one design and ordering assistance. SIMPLE. STRONG.
6 | 360.323.5416 | STAINLESSCABLERAILING.COM Contents Introduction 4 How to Order 9 Product & Material Info 10 CableView® Aluminum 12 Aluminum Posts 18 Aluminum Top Rails 26 Anodized Aluminum 42 Stainless Steel 44 Stainless Posts 50 Stainless Top Rails 68 Duplex 2507 Stainless 78 Wood 80 Premium Wood Posts 86 Premium Wood Top Rails 90 Cable, Fittings, & Tools 94 Thru-Post Fittings 104 To-Post Fittings 120 Stainless Cable 136 Cable Railing Kits 140 Tools & Hardware 148 A B
STAINLESSCABLERAILING.COM | 360.323.5416 | 7 Terms & Conditions 152 Warranty & Resources 154 Online Resources 154 Estimate Request Form 155 PHOTOS A. CableView® Aluminum in Black, Wood Top Rail B. CableView® Aluminum in Bronze, Post-to-Post w/ Cedar Rail C. CableView® Aluminum in Black, Post-to-Post Rail D. CableView® Aluminum in Bronze, Post-to-Post w/ Wood Rail E. Stainless Round, FineLine Button Assemblies F. Stainless Square, Balau Top Rail C D F E
8 | 360.323.5416 | STAINLESSCABLERAILING.COM Simple. Strong.
360.323.5416 stainlesscablerailing.com How to Order 1. Call 360.323.5416 and talk to a railing expert for a free estimate. 2. Go to stainlesscablerailing.com and click on the blue button for a free estimate. 3. Order online at stainlesscablerailing.com. All orders are reviewed by a railing expert. 4. Mail in the order form on page 155.
10 | 360.323.5416 | STAINLESSCABLERAILING.COM About Our Products POWDER-COATED ALUMINUM Aluminum is a light-weight metal that is easy to work with, economical, and recyclable. It is often a favorite material for small construction projects like deck railings. Our posts are designed and reinforced specifically to handle the tension of cable infill and are covered with a powder coat that helps prevent corrosion. For this reason, our aluminum systems remain a customer favorite and are the best option for most cable railing applications. The powder coat is available in five color options. CARE: Wipe down as needed. If any color gets scratched off during installation or use, we offer touch-up paint for each powder coat color. We also recommend using the touch-up paint to coat any fresh cuts or holes in the posts, to minimize the possibility of corrosion. PREMIUM WOOD Wood is a classic construction material that offers a unique rustic aesthetic. It is naturally recyclable and rust-free. Our wood options are strong and dense, allowing them to withstand cable tension. We offer exotic and domestic woods in a range of pigments for full systems or as top rails for metal posts. Our top rails are high-grade and handpicked from our local supplier, while our post options are uniquely engineered for additional strength and visual consistency. All of our wood offerings are sustainably harvested. CARE: Though these wood varieties are durable, we recommend using protective deeppenetrating oil treatments (available through our online store) to preserve their color and appearance. Treatments can be skipped, if desired, so the wood naturally fades to a silver hue. Staining or painting are also options available with this material type. STAINLESS STEEL Stainless Steel is a more dense metal that boasts not only superior strength, but breathtaking beauty. Marine Grade 316 is the most lustrous and corrosion-resistant grade of stainless steel, offering a stronger passive layer to protect the steel from staining. This durable material is the standard for marine applications and is the same metal used for the cable infill of cable railing systems. It is naturally resistant to bending and corrosion. Due to its strength, beauty, and resilience, stainless steel has become an increasingly popular option for cable railing applications, especially where superior durability and luster are desired. Round and square shapes are available. CARE: Wipe down as needed. Use passivation solution for deep cleaning and to reinforce the passive layer. Use regularly and as needed to protect it from corrosion. Increase frequency in corrosive environments.
Good Better Best *See page 154 for warranty details STAINLESSCABLERAILING.COM | 360.323.5416 | 11 Material Comparison CableView® Aluminum CableView® Stainless Cableview® Wood Maintenance Low- wipe down occasionally Low- wipe down occasionally Low- wipe down occasionally Aesthetics Clean powder-coat with 5 color options Brushed finish; round and square options High-grade timber; domestic and exotic options Warranty 5-year for powder-coat 10-year for structural integrity* 10-year for structural integrity* 10-year for structural integrity* Durability Weather-Resistance Marine-Friendly Mold/Mildew Resistance Stain Resistance Scratch Resistance Ease of Installation Initial Cost $$ $$$ $$
Aluminum Versatile, cost-effective, and engineered for cable railing applications. CableView® Aluminum in Bronze Rectangular Top Rail
• Lowest cost • Powder-coat color options • Impervious to termites, ants, etc. • Sustainable building material ALUMINUM • Shortest lead time
CableView® Aluminum in Black, Wood Top Rail
STAINLESSCABLERAILING.COM | 360.323.5416 | 15 ALUMINUM CABLEVIEW® ALUMINUM POSTS Powder-coated aluminum posts are engineered with reinforced walls to withstand the tension of cable infill. FEATURES & BENEFITS • Simple, strong design. Perfect for cable railing • Light and easy to install • Does not require custom fabrication; Off-the-shelf system (ready to package and ship faster than other options) • Powder-coated for protection from the elements • Engineered design and reinforced walls make our posts stronger than our competitors’ posts TOP / DECK MOUNT SIDE / FASCIA MOUNT GROUND / CORE MOUNT POST COLORS POST MOUNTS From left to right: BRONZE NATURAL WHITE BLACK “Stainless Cable & Railing sell top notch products. I really liked the fasteners and mounts they sell as it made my project doable and come out looking great. It is a company that stands by the quality products they sell.” – Mark, San Francisco, CA
CableView® Aluminum in Black Rectangular Top Rail
LINK HANDRAIL • ADA-compliant, graspable handrail • Easily accommodates stairs and bends • Smooth, versatile shape STAINLESSCABLERAILING.COM | 360.323.5416 | 17 ALUMINUM POST-TO-POST RAIL • Thinner rail. Ideal for handrails • Easily accommodates stairs and bends POST TO POST + WOOD TOP RAIL • Post-To-Post supports thin wood rails • Visually ties metal and wood together RECTANGULAR TOP RAIL • Most popular shape; matches posts • Flat top makes it a usable surface SHAPED TOP RAIL • Smooth, domed design • Unique shape for a top rail • Rounded top sheds rain WOOD TOP RAIL • High-grade Exotic and Cedar species • Several length & dimension options
18 | 360.323.5416 | STAINLESSCABLERAILING.COM DECK MOUNT POSTS Deck mount posts attach to the top of a deck or other surface using an included base plate assembly. Installation is relatively simple and can be completed by a single person, if necessary. Our aluminum posts are engineered specifically for cable railing systems. The reinforced walls of our terminal posts are designed to resist bending so your railing can withstand the tension of taut cable infill. FEATURES & BENEFITS • Post attaches to the top of a surface for relatively simple installation • Base plate assemblies included • Reinforced walls withstand the tension of cable infill • Four powder-coat colors and five top rail options available TERMINAL (END POSTS) Corner Posts Double offset posts are recommended for corners. For more design options, please contact our sales professionals. ESTIMATOR TIP Part # Dimensions Final Rail Height Drilled Color 729646 2.38” x 2.38” x 37” 36” above surface Yes, 11 holes Black 734589 2.38” x 2.38” x 48” 42” above surface Yes, 13 holes Black 729790 2.38” x 2.38” x 48” 36” or 42” Undrilled Black 729653 2.38” x 2.38” x 37” 36” above surface Yes, 11 holes Bronze 734572 2.38” x 2.38” x 48” 42” above surface Yes, 13 holes Bronze 729806 2.38” x 2.38” x 48” 36” or 42” Undrilled Bronze 729677 2.38” x 2.38” x 37” 36” above surface Yes, 11 holes Natural 734558 2.38” x 2.38” x 48” 42” above surface Yes, 13 holes Natural 729820 2.38” x 2.38” x 48” 36” or 42” Undrilled Natural 729684 2.38” x 2.38” x 37” 36” above surface Yes, 11 holes White 734541 2.38” x 2.38” x 48” 42” above surface Yes, 13 holes White 729837 2.38” x 2.38” x 48” 36” or 42” Undrilled White
STAINLESSCABLERAILING.COM | 360.323.5416 | 19 ALUMINUM POSTS INTERMEDIATE (IN-BETWEEN) SQUARE BASE PLATE ASSEMBLIES INSTALLATION DETAIL Part # Dimensions Final Rail Height Drilled Color 729592 2.38” x 2.38” x 48” 36” or 42” Yes, 13 holes Black 729691 2.38” x 2.38” x 48” 36” or 42” Undrilled Black 729608 2.38” x 2.38” x 48” 36” or 42” Yes, 13 holes Bronze 729707 2.38” x 2.38” x 48” 36” or 42” Undrilled Bronze 729622 2.38” x 2.38” x 48” 36” or 42” Yes, 13 holes Natural 729721 2.38” x 2.38” x 48” 36” or 42” Undrilled Natural 729639 2.38” x 2.38” x 48” 36” or 42” Yes, 13 holes White 729738 2.38” x 2.38” x 48” 36” or 42” Undrilled White Part # Color 733131 Black 733148 Bronze 733179 Natural 733186 White
20 | 360.323.5416 | STAINLESSCABLERAILING.COM FASCIA / CORE MOUNT POSTS Fascia mount posts attach to the side of a deck or other surface. This installation method is particularly discreet, preserves your usable surface area, and creates the illusion of additional space. Our aluminum posts are engineered specifically for cable railing systems. The reinforced walls of our terminal posts are designed to resist bending so your railing can withstand the tension of taut cable infill. FEATURES & BENEFITS • Post attaches to the side of a surface to preserve your space • Only mounting screws are necessary for attachment • Reinforced walls withstand the tension of cable infill • Four powder-coat colors and five top rail options available • Bottom post caps included TERMINAL (END POSTS) Standoff Spacer Use when mounting to a deck with a drip edge. Stack multiple for larger drip edges. (P.22) ESTIMATOR TIP Part # Dimensions Final Rail Height Drilled Color 729844 2.38” x 2.38” x 48” 36” or 42” Yes, 13 holes Black 734480 2.38” x 2.38” x 48” 36” or 42” Undrilled Black 729851 2.38” x 2.38” x 48” 36” or 42” Yes, 13 holes Bronze 734497 2.38” x 2.38” x 48” 36” or 42” Undrilled Bronze 729875 2.38” x 2.38” x 48” 36” or 42” Yes, 13 holes Natural 734510 2.38” x 2.38” x 48” 36” or 42” Undrilled Natural 729882 2.38” x 2.38” x 48” 36” or 42” Yes, 13 holes White 734527 2.38” x 2.38” x 48” 36” or 42” Undrilled White
STAINLESSCABLERAILING.COM | 360.323.5416 | 21 ALUMINUM POSTS INTERMEDIATE (IN-BETWEEN) POST CAP (BOTTOM OF POST) INLINE FASCIA BRACKET CORNER FASCIA BRACKET INSTALLATION DETAIL *All four colors available. **Bronze, natural, white, and raw options also available Part # Dimensions Final Rail Height Drilled Color 734633 2.38” x 2.38” x 48” 36” or 42” Yes, 13 holes Black 012155 2.38” x 2.38” x 48” 36” or 42” Undrilled Black 729752 2.38” x 2.38” x 48” 36” or 42” Yes, 13 holes Bronze 734626 2.38” x 2.38” x 48” 36” or 42” Undrilled Bronze 729776 2.38” x 2.38” x 48” 36” or 42” Yes, 13 holes Natural 734602 2.38” x 2.38” x 48” 36” or 42” Undrilled Natural 729783 2.38” x 2.38” x 48” 36” or 42” Yes, 13 holes White 734596 2.38” x 2.38” x 48” 36” or 42” Undrilled White Part # Type Color 983366 Terminal Black* 983359 Intermediate Black* Part # Color 018997 Black** Part # Color Type 711439 Black** Inside 711484 Black** Outside
22 | 360.323.5416 | STAINLESSCABLERAILING.COM 3/8” HEX BOLT ASSEMBLIES (POST ATTACHMENT) 3/8” LAG SCREW ASSEMBLIES (POST ATTACHMENT) Part # Length Material 012735 1” 316 SS 012742 2” 316 SS 012759 2.5” 316 SS 012766 4” 316 SS 012773 5” 316 SS 012780 5.5” 316 SS 012797 6” 316 SS 012803 6.5” 316 SS 012810 7” 316 SS 012827 8” 316 SS Part # Length Material 012858 2” 316 SS 012834 2.5” 316 SS 018669 4.5” 316 SS 012865 6” 316 SS ALUMINUM POST HARDWARE & ACCESSORIES STANDOFF SPACER (FASCIA MOUNTING W/DRIP EDGE) DRILL BIT (POST CAP INSTALLATION) HANDRAIL SADDLE BRACKET *All four colors available. Part # Post Type Color 013671 Terminal Black* 013626 Intermediate Black* Part # 987647 Part # Material 732486 SS 316
STAINLESSCABLERAILING.COM | 360.323.5416 | 23 Handrail Saddle Bracket Allows your stair handrail to run continuously over your posts. ESTIMATOR TIP ALUMINUM POSTS Hex Bolts Typically used for fascia mounting. Common size: 7” ESTIMATOR TIP Lag Bolts Typically used for deck mounting. Common size: 4.5” ESTIMATOR TIP DTT2Z CONNECTORS (FASCIA MOUNTING SUPPORT) DROP-IN ANCHORS (POST ATTACHMENT TO CONCRETE) 3/8” HEX BOLT ASSEMBLIES (POST ATTACHMENT) ANCHOR SCREWS (ATTACHMENT TO CONCRETE) 3/8” LAG SCREW ASSEMBLIES (POST ATTACHMENT) Part # Dimensions 985964 1/4” - 20 985971 3/8” - 16 Part # Dimensions Material 016955 3/8” x 1 1/4” SS 410 982925 3/8” x 2 1/2” SS 410 019352 3/8” x 3” SS 410 019345 3/8” x 5” SS 410 Part # 729288 Part # Length Material 987470 1” 304 SS 987463 1.5” 304 SS 987494 2” 304 SS 987487 2.5” 304 SS 987500 4” 304 SS 020617 4.5” 304 SS 987524 5” 304 SS 987517 5.5” 304 SS 987548 6” 304 SS 987531 6.5” 304 SS 987562 7” 304 SS 987555 7.5” 304 SS 987579 8” 304 SS Part # Length Material 987586 2.5” 304 SS 019833 4.5” 304 SS 991507 5.5” 304 SS 991514 6” 304 SS 991521 7” 304 SS 991491 8” 304 SS Stainless Grades Use our 316 SS attachment hardware in particularly corrosive environments. ESTIMATOR TIP
24 | 360.323.5416 | STAINLESSCABLERAILING.COM When stainless steel cables and hardware come into contact with exposed aluminum components, the dissimilar metals interact with each other, resulting in galvanic corrosion. The best way to prevent this type of corrosion is through keeping the two metals separate, which is part of the reason we powder-coat all of our aluminum products. We also dip-spin the screws included with our base plates in brush-on electrical tape to prevent corrosion within the post screw chases. To further ensure these metals stay out of contact, we have developed specialized products for our customers. Our screw covers are composed of three pieces that snap together around any post-mounting bolt or lag. They completely envelope each part of the screw that would otherwise come into contact with the aluminum base plate or post. Order 4 covers per base plate or 2 per fascia-mounted post. In addition to the incidental touching-up of any scratches or nicks acquired during installation, our touch-up paint also doubles as a brush-on isolator. After cutting the ends of your aluminum posts or drilling holes, coat the fresh edges with touch-up paint to cover the raw aluminum and seal the protective paint layer. Screw Covers Easy to lose in the field. Order 5% extra. ESTIMATOR TIP Touch-Up Paint Use after cutting or drilling holes into your posts. ESTIMATOR TIP Aluminum Isolation SCREW COVERS (POST HARDWARE) Part # Color 712344 Black 712351 Bronze 712375 Natural 712382 White TOUCH-UP PAINT Part # Color 729547 Black 729554 Bronze 729578 Natural 729585 White ****All four colors available. Specify color when ordering.
STAINLESSCABLERAILING.COM | 360.323.5416 | 25 ALUMINUM POSTS GROMMETS (INLINE RUNS*) Part # Post Type 715833 Terminal** 013046 Intermediate PVC SLEEVES (FOR STAIRS) INSTALLATION DETAIL GROMMETS FOR ALUMINUM POST HOLES These products keep your cables from coming into direct contact with the walls of your posts, both reducing the chances of galvanic corrosion and reducing noise caused by wind-rattle. We recommend these products for any customers in particularly corrosive and/or windy environments. Part # Post Type 715840 Terminal** 732868 Intermediate *Free installation tool with orders that include grommets. **Terminal options include one washer per grommet or sleeve. Intermediate options do not include washers. NOTE: While these methods help to prevent galvanic corrosion, your stainless steel cables may still accumulate other types of corrosion through exposure to the elements. We recommend periodically treating your cables using our maintenance products to properly protect them. See p.65 for more details.
26 | 360.323.5416 | STAINLESSCABLERAILING.COM ALUMINUM RECTANGULAR TOP RAIL The aluminum rectangular top rail offers a classic angular look as well as a usable flat surface for placing drinks and other small objects. It is designed specifically to attach to our engineered aluminum posts. This rail is hollow and bottomless, allowing for most of the attachment hardware to be concealed inside. The hollow interior is then sealed with a snap cover (sold separately). FEATURES & BENEFITS • Traditional and functional top rail design • Fits seamlessly with our aluminum posts • Most hardware is concealed • Necessary screws included RECTANGULAR TOP RAIL Part # Dimensions Color 983380 3.15” x 2.26” x 20’ Black 983786 3.15” x 2.26” x 20’ Bronze 984431 3.15” x 2.26” x 20’ Natural 984806 3.15” x 2.26” x 20’ White Splices For long railing sections, use a splice to connect separate top rail pieces. Use two for corner rail connections. ESTIMATOR TIP
STAINLESSCABLERAILING.COM | 360.323.5416 | 27 ALUMINUM RAILS Part # 987630 Part# Angle Color 729196 90 degree Black* 982987 Custom Black* Part # Color 711781 Black* Part # Color 729356 Black* *All four colors available. Part # 984936 ALUMINUM TOP RAIL SNAP COVER DRILL BIT KIT FOR TOP RAIL & CORNER INSTALLATION RECTANGULAR CORNER PIECE W/ SCREWS TOUCH-UP PAINT RECTANGULAR TOP RAIL END CAP TOP RAIL SPLICE W/ SCREWS Part # Color 729547 Black* “After much research, I chose the Stainless Cable and Rail System and was happy I made the right decision. The product is well engineered, the service was excellent, and the system is easy to install.” – Larry, Long Grove, IL
28 | 360.323.5416 | STAINLESSCABLERAILING.COM ALUMINUM SHAPED TOP RAIL The aluminum shaped top rail offers a uniquely rounded look that softens and minimizes visual impact while effortlessly shedding rain. It is designed specifically to fit on and attach to our engineered aluminum posts. This rail is hollow and bottomless, allowing for most of the attachment hardware to be concealed inside. The hollow interior is then sealed with a snap cover (sold separately). FEATURES & BENEFITS • Uniquely rounded top rail design • Fits seamlessly with our aluminum posts • Most hardware is concealed • Necessary screws included SHAPED TOP RAIL Part # Dimensions Color 983410 3.54” x 1.89” x 20’ Black 983809 3.54” x 1.89” x 20’ Bronze 984455 3.54” x 1.89” x 20’ Natural 984837 3.54” x 1.89” x 20’ White Splices For long railing sections, use a splice to connect separate top rail pieces. Use two for corner rail connections. ESTIMATOR TIP
STAINLESSCABLERAILING.COM | 360.323.5416 | 29 ALUMINUM RAILS “We love the railing!! So glad we took our time deciding and then came across your site. We get nothing but compliments about your railing and how it doesn’t obstruct the view of the lake.” – Calvin, Fishing Lake, Saskatchewan Part # 987630 Part# Angle Color 729196 90 degree Black* 982987 Custom Black* Part # Color 711781 Black* Part # Color 729356 Black* *All four colors available. Part # 984936 ALUMINUM TOP RAIL SNAP COVER DRILL BIT KIT FOR TOP RAIL & CORNER INSTALLATION RECTANGULAR CORNER PIECE W/ SCREWS TOUCH-UP PAINT RECTANGULAR TOP RAIL END CAP TOP RAIL SPLICE W/ SCREWS Part # Color 729547 Black*
30 | 360.323.5416 | STAINLESSCABLERAILING.COM ALUMINUM POST-TO-POST RAIL Our Post-to-Post Rail is incredibly versatile and can be used either as an independent handrail or as a support rail for wood. There are three options for handrail use: inline, stair, and stand-alone. The inline handrail runs between posts in a straight or curved flat run. The stair rail runs continuously between the first and last post of a stair section, supported by handrail saddle brackets on the posts in between. The standalone option is typically mounted to a wall, but can also be mounted to the sides of posts at a slightly lower height than the top rail. Alternatively, the inline and stair options can be used as support rails. They will bear the tension of the cable infill and provide a flat surface for the wood to be mounted on. This prevents sagging, especially for thinner wood rails, and allows for easy top rail replacement. INLINE HANDRAIL / SUPPORT RAIL (WOOD TOP) Part # Dimensions Color Length 733827 1.97” x 1.18” Black 2’ 733926 1.97” x 1.18” Bronze 2’ 734121 1.97” x 1.18” Natural 2’ 734213 1.97” x 1.18” White 2’ Stair Rail Creates an ADA-compliant, graspable and continuous handrail. ESTIMATOR TIP Stand-Alone Handrail Attach to a wall or use as an auxiliary 36” handrail on a 42” system. ESTIMATOR TIP FEATURES & BENEFITS • Runs between posts, allowing for easy accommodation of changes in direction, both vertically and horizontally • Thinnest aluminum rail option for minimal visual obstruction and easy grasping • Can be used and mounted in a variety of ways depending on the needs of your project INCLUDES • 1 Post-to-Post Inline Rail • 2 Inline Mounting Bracket Assemblies (includes screws)
STAINLESSCABLERAILING.COM | 360.323.5416 | 31 ALUMINUM RAILS STAIR RAIL / SUPPORT RAIL (WOOD TOP) STAND ALONE HANDRAIL (MOUNTS TO WALL OR POSTS) Part # Dimensions Color Length 733810 1.97” x 1.18” Black 2’** 733919 1.97” x 1.18” Bronze 2’** 734114 1.97” x 1.18” Natural 2’** 734206 1.97” x 1.18” White 2’** INCLUDES • 1 Post-to-Post Stair Rail • 2 Stair Mounting Bracket Assemblies (includes screws) Part # Dimensions Color Length 020556 1.97” x 1.18” Black 2’ 983557 1.97” x 1.18” Bronze 2’ 984233 1.97” x 1.18” Natural 2’ 991484 1.97” x 1.18” White 2’ INCLUDES • 1 Post-to-Post Handrail • 2 Wall-Return Assemblies
32 | 360.323.5416 | STAINLESSCABLERAILING.COM Handrail Saddle Bracket These allow your stair handrail to run continuously over your posts. ESTIMATOR TIP Part # 984912 Part # Color 730246 Nickel 730222 Oil-Rubbed Bronze 730215 Black Part # Run Type 984905 Flat / Straight 984929 Inline / Stairs / Curves Part # 987777 Part # Post Type Color 983366 Terminal Black* 983359 Intermediate Black* POST-TO-POST 90 DEGREE CORNER POST-TO-POST CUSTOM CORNER HANDRAIL SADDLE BRACKET WALL MOUNT SADDLE BRACKET W/ SCREWS POST CAP FOR TOP OF POST POST-TO-POST MOUNTING BRACKET SCREW & WASHER FOR P2P TO WOOD RAIL INSTALL DRILL BIT FOR P2P TO WOOD RAIL INSTALL *All four aluminum colors available: black, bronze, natural, and white. Part # Post Type Color 013671 Terminal Black* 013626 Intermediate Black* Part # Color 983038 Black* Part # Color 983021 Black*
CableView® Aluminum in Black Post-to-Post Rail
34 | 360.323.5416 | STAINLESSCABLERAILING.COM WOOD TOP RAILS FOR ALUMINUM POSTS Our premium wood top rails are made from durable, low-maintenance species. Add natural beauty to your cable railing with our exotic and domestic options. Balau Mahogany is a deeply-colored, red-hued tropical wood. Balau offers a greater range of tones marbled together. Western Red Cedar is a lighter-colored North American natives. Western Red is slightly darker and more red in color. This wood is also lightweight, making it easy to work with. FEATURES & BENEFITS • Available wood species are strong, durable, and rot/insect resistant • Unique, natural top rail option that pairs beautifully with any post material • All options are hand-picked and high quality. Balau rails are kiln-dried for additional strength • Western Red Cedar “Select Tight Knot” options available, for a more economic, rustic alternative to “Clear Grain” • Install directly to aluminum posts using mounting plates, or attach to an inline or stair Post-To-Post Rail (see p.38-40) BALAU MAHOGANY Part # Grade Nominal Size*** 989047 2” x 4” x 10’ 989054 2” x 4” x 15’ 989061 2” x 4” x 20’ 989078 5/4”* x 4” x 10’ 989085 5/4”* x 4” x 15’ 989092 5/4”* x 4” x 18’ 989108 5/4”* x 4” x 19’ 989115 5/4”* x 4” x 20’ 014456 5/4”* x 6” x 10’ Architectural Grade Heartwood Clear Vertical Grain *5/4” rails require Post-to-Post Rail underneath for support. See pages 30-32. **Additional lengths available up to 20’ ***Actual board dimensions are smaller than nominal size as per industry standards. WESTERN RED CEDAR Part # Grade Nominal Size*** 989887 2” x 4” x 5’** 989436 5/4”* x 4” x 10’** Clear Vertical Grain
STAINLESSCABLERAILING.COM | 360.323.5416 | 35 Part # Color 982963 Black**** RAILS ****All four colors available. Specify color when ordering. MOUNTING PLATE (ASSEMBLY FOR 2X4 RAIL) MOUNTING PLATE (ASSEMBLY FOR 2X6 RAIL) ALUMINUM MOUNTING PLATE TO RAIL ATTACHMENT SCREW Part # 730390 Part # Color 982970 Black****
36 | 360.323.5416 | STAINLESSCABLERAILING.COM WOOD CARE PRODUCTS Penofin Deep Penetration Oil Treatment protects the integrity and color of wood decks and railings. With rosewood oil as the main ingredient, this environmentally-friendly solution soaks into the wood, providing moisture from the inside out. It helps the wood resist weathering and fading from UV rays, rain, and more. We recommend applying this treatment immediately after or up to a year following installation. Reapply as needed. The woods we carry can be left untreated, if desired, and will naturally fade to a lighter, silver color. Quart containers will cover approximately 43-75 square feet, while gallon containers will cover approximately 175-300 square feet. Choose the solution that is right for your project. PENOFIN (CEDAR & DOMESTIC WOODS) Part # VOC Size 734411 550 Quart 734398 550 Gallon 734404 250 Quart 734381 250 Gallon PENOFIN (EXOTIC HARDWOODS) Part # VOC Size 734374 550 Quart 733216 550 Gallon 734367 250 Quart 734350 250 Gallon “We are 20’ above the water, and all of our views are down. The stainless cable railing has been a “wow” for everyone who has seen the difference from our old vertical wooden spindles that blocked a clear view.” – Chris, Lake Huron, Cedarville, MI
STAINLESSCABLERAILING.COM | 360.323.5416 | 37 WOOD INSTALLATION PRODUCTS ALUMINUM RAILS Part # 732660 10X3” SQUARE DRIVE DECK SCREW WOOD FRAME INSTALLATION KIT WOOD PLUGS 100 PACK TOP RAIL INSTALLATION KIT TITEBOND WOOD GLUE Part # 987715 Part # 988903 Part # 987784 Part # 732820 “SCR provided prompt support and excellent written instructions for installing the stainless cable on our deck project. I would recommend them to others willing to do the work themselves.” – Rick, Cincinnati, OH
38 | 360.323.5416 | STAINLESSCABLERAILING.COM ALUMINUM LINK HANDRAIL The Link Handrail is designed to be ADA-compliant, for projects where building codes and hand support are especially important, or where a round aluminum rail is desired. The shape is comfortable to grasp and handles changes in direction more easily than rectangular rails. Mounts to posts or walls using matching brackets. FEATURES & BENEFITS • Graspable, ADA-compliant size and shape • Smoothly handles changes in direction for stair sections • Same material and colors as our other aluminum products • Easy installation; most components snap together • Matching powder-coated screws included where necessary LINK HANDRAIL Part # Dimensions Color 711576 1.5” OD x 20’ Black 711606 1.5” OD x 20’ Bronze 711583 1.5” OD x 20’ Natural 711590 1.5” OD x 20’ White Splices For long railing sections, use a splice to connect separate top rail pieces. Use two for corner rail connections. ESTIMATOR TIP *Bronze, natural, white, and custom powdercoat options also available. **Made custom upon request. Can be powder-coated your desired color for an additional charge.
STAINLESSCABLERAILING.COM | 360.323.5416 | 39 ALUMINUM RAILS Part # Angle Color 017747 90 degree Black* 730468 Adjustable Black* 016740 Any None** Part # Type Color 017839 End Cap Black* 017990 Return Black* Part # Color 017792 Black* Part # 016795 LINK HANDRAIL END LOOP LINK HANDRAIL WALL/POST BRACKET LINK HANDRAIL CORNER TOUCH-UP PAINT LINK HANDRAIL END CAP LINK HANDRAIL SPLICE Part # Color 729547 Black* Part # Color 018034 Black* “I’m very happy with my cable railing kit from stainlesscablerailing.com. The included finished cable end terminations really set the system apart from others on the market, and the price can’t be beat! I will be using their cable railing kits on any future railing project I have.” – Tom, Santa Rosa, CA *All four colors available. Specify color when ordering.
CableView® Aluminum in White Rectangular Top Rail & Matching Custom Gate
STAINLESSCABLERAILING.COM | 360.323.5416 | 41 ALUMINUM CABLEVIEW GATE Our Aluminum Gates are custom made for your project. We weld our posts into a rectangular frame that fits your desired dimensions, then fill it in with our low-profile button assemblies to keep the sides of the gate as flat as possible. This gate seamlessly matches the rest of our aluminum railing system. Latch, hinges, and gate stop are included with each custom gate. INSTALLATION DETAIL INCLUDES • 1 gate • 1 latch • 1 gate stop • 2 hinges ALUMINUM CABLEVIEW GATE Part # Color 984844 Black 984844 Bronze 984844 Natural 984844 White FEATURES & BENEFITS • Made using the posts of our aluminum railing system • Horizontal or vertical cables available • Gate custom-made to meet your dimensions and needs • Includes latch, hinges, and gate stop • Low-profile button hardware keeps the sides as flat as possible for full movement with minimal gaps ALUMINUM RAILS
Anodized Aluminum 42 | 360.323.5416 | STAINLESSCABLERAILING.COM RECTANGULAR TOP RAIL Part # Dimensions Color 710562 3.15” x 2.26” x 20’ Black 710739 3.15” x 2.26” x 20’ Clear INLINE HANDRAIL / SUPPORT RAIL ANODIZED TOP RAIL SNAP COVER RECTANGULAR CORNER PIECE W/ SCREWS RECTANGULAR TOP RAIL END CAP Part # Dimensions Color Type 710234 1.97” x 1.18” x 1’** Black Inline 710357 1.97” x 1.18” x 2’** Black Stair 710753 1.97” x 1.18” x 1’** Clear Inline 710876 1.97” x 1.18” x 2’** Clear Stair Part # Dimensions Color 020129 20’ Black 019475 20’ Clear Part # Color 710708 Black 710715 Clear Part # Color 710555 Black 710722 Clear At SC&R we are always striving to offer the most durable products and designs available. While our standard powdercoated aluminum is resilient enough for most environments, it’s no match for particularly corrosive locations, such as by the ocean. Anodized aluminum, however, can handle the salty air no problem, allowing customers along the coast to install our aluminum systems without concern for corrosion. These products are the same in construction as our standard aluminum products, but with an anodized coating and beautiful brushed finish in black or clear color options. This is a new line that is still being finalized and procured at the time of publication. Call us at 360.323.5416 to ask about our product availability and prices!
ALUMINUM RAILS Part # Post Type* Color 710135 Intermediate Black 710616 Intermediate Clear 710166 Terminal Black 710647 Terminal Clear *Available for 36” or 42” final rail heights. Drilled or undrilled options available. **Additional lengths available, up to 20’. NOTE: This line is still in production at the time of publication. The images used here depict our standard powdercoated aluminum products, which are the same shape and material. The anodized line will have a brushed, metallic finish, rather than glossy. Call us at 360.323.5416 for product availability! ANODIZED BASE PLATES ANODIZED DECK MOUNT POST TOP RAIL SPLICE W/ SCREWS ANODIZED FASCIA MOUNT POST Part # Post Type* Color 710203 Intermediate Black 710678 Intermediate Clear 710227 Terminal Black 710692 Terminal Clear Part # Type Color 710104 Post Mount Black 710586 Post Mount Clear 710111 Rail Mount Black 710593 Rail Mount Clear Part # 984936 DRILL BIT KIT FOR TOP RAIL & CORNER INSTALLATION Part # 987630 STAINLESSCABLERAILING.COM | 360.323.5416 | 43
Stainless Strong, resilient, and lustrous 316 Stainless Steel cable railing posts and rails. CableView® Stainless Round Posts Wood Top Rail
• Marine Grade 316 Stainless • Beautiful brushed finish • Impervious to termites, ants, etc. • Corrosion-resistant; Low-maintenance • Round and Square/Rectangular shape options • Fabricated specifically for your project STAINLESS STEEL
CableView® Aluminum in Black Rectangular Top Rail Stainless Steel Round Railing
STAINLESSCABLERAILING.COM | 360.323.5416 | 47 CABLEVIEW® STAINLESS STEEL POSTS Marine Grade 316 stainless steel posts in round and square shapes. ROUND SQUARE SIDE / FASCIA MOUNT POST SHAPES POST MOUNTS STAINLESS STEEL FEATURES & BENEFITS • Marine Grade 316 stainless is structurally strong and resistant to corrosion • Ideal for coastal areas and other corrosive environments • Same material as our cables and fittings • Passivated prior to shipping for additional resilience • Minimal, contemporary, and industrial in aesthetic • All posts are custom fabricated to fit the needs of each job TOP / DECK MOUNT GROUND / CORE MOUNT
Stainless Steel Square Posts, Wood Top Rail
STAINLESSCABLERAILING.COM | 360.323.5416 | 49 STAINLESS STEEL 2” STAINLESS ROUND RAIL • 2” Outer Diameter Top Rail or Handrail • Matches our Stainless Round Posts • Minimal and contemporary 1.5” STAINLESS ROUND HANDRAIL • 1.5” Outer Diameter for Handrail • Matches our Round Posts & Rail, but slightly thinner and more graspable FLAT STAINLESS RAIL • 2” width for top rail or handrail • 0.5” thickness; our thinnest rail • Visually minimal, with clean lines WOOD TOP RAIL • High-grade Exotic & Cedar species • Several length & dimension options
50 | 360.323.5416 | STAINLESSCABLERAILING.COM ROUND DECK MOUNT POSTS Deck mount posts attach to the top of a deck or other surface using a flange (sold separately), which is attached to the post using epoxy. This style of installation is relatively simple and can be completed by a single person, if necessary. Our stainless steel posts are naturally strong and easily handle the tension of cable infill. The material is also corrosion-resistant, making it ideal for outdoor applications in marine environments. FEATURES & BENEFITS • Post attaches to the top of a surface for relatively simple installation • Flanges and post caps can be attached using epoxy (DIY friendly and more economical; sold separately on p.62) or can be ordered prewelded to posts (to meet stricter building codes; see p.54) • Naturally strong, corrosion-resistant material with a brushed finish • Passivated prior to shipping for long-lasting protection TERMINAL (END POSTS) Part # Dimensions Final Rail Height Drilled 988675 2” Outer Diameter 36” above surface No, undrilled 988682 2” Outer Diameter 42” above surface No, undrilled 714355 2” Outer Diameter 36” above surface Yes, 11 holes for 1/8” cable 714362 2” Outer Diameter 36” above surface Yes, 11 holes for 3/16” cable 714379 2” Outer Diameter 42” above surface Yes, 13 holes for 1/8” cable 714386 2” Outer Diameter 42” above surface Yes, 13 holes for 3/16” cable Corner Posts Double offset posts are recommended for corners. For more design options, please contact our sales professionals. ESTIMATOR TIP
STAINLESSCABLERAILING.COM | 360.323.5416 | 51 POSTS INTERMEDIATE (IN-BETWEEN) INSTALLATION DETAIL STAINLESS STEEL Part # Post Type 733094 Terminal 731458 Intermediate FLOOR / WALL FLANGES Part # 731441 NARROW FLANGE FLANGE COVER PLATE Part # 733803 Part # Dimensions Final Rail Height Drilled 988613 2” Outer Diameter 36” above surface No, undrilled 988620 2” Outer Diameter 42” above surface No, undrilled 714270 2” Outer Diameter 36” above surface Yes, 11 holes for 1/8” cable 714287 2” Outer Diameter 36” above surface Yes, 11 holes for 3/16” cable 714294 2” Outer Diameter 42” above surface Yes, 13 holes for 1/8” cable 714300 2” Outer Diameter 42” above surface Yes, 13 holes for 3/16” cable For stainless maintenance products see page 65.
52 | 360.323.5416 | STAINLESSCABLERAILING.COM SQUARE DECK MOUNT POSTS Deck mount posts attach to the top of a deck or other surface using a flange (sold separately), which is attached to the post using epoxy. This style of installation is relatively simple and can be completed by a single person, if necessary. Our stainless steel posts are naturally strong and easily handle the tension of cable infill. The material is also corrosion-resistant, making it ideal for outdoor applications in marine environments. FEATURES & BENEFITS • Post attaches to the top of a surface for relatively simple installation • Flanges and post caps can be attached using epoxy (DIY friendly and more economical; sold separately on p.63) or can be ordered prewelded to posts (to meet stricter building codes; see p.54) • Naturally strong, corrosion-resistant material with a brushed finish • Passivated prior to shipping for long-lasting protection TERMINAL (END POSTS) Part # Dimensions Final Rail Height Drilled 988057 2” x 2” 36” above surface No, undrilled 988064 2” x 2” 42” above surface No, undrilled 714454 2” x 2” 36” above surface Yes, 11 holes for 1/8” cable 714461 2” x 2” 36” above surface Yes, 11 holes for 3/16” cable 714492 2” x 2” 42” above surface Yes, 13 holes for 1/8” cable 714508 2” x 2” 42” above surface Yes, 13 holes for 3/16” cable Corner Posts Double offset posts are recommended for corners. For more design options, please contact our sales professionals. ESTIMATOR TIP
STAINLESSCABLERAILING.COM | 360.323.5416 | 53 POSTS INTERMEDIATE (IN-BETWEEN) INSTALLATION DETAIL STAINLESS STEEL Part # Post Type 731236 Terminal 731229 Intermediate FLOOR / WALL FLANGES FLANGE COVER PLATES Part # Dimensions Final Rail Height Drilled 987975 2” x 2” 36” above surface No, undrilled 987982 2” x 2” 42” above surface No, undrilled 714430 2” x 2” 36” above surface Yes, 11 holes for 1/8” cable 714447 2” x 2” 36” above surface Yes, 11 holes for 3/16” cable 714478 2” x 2” 42” above surface Yes, 13 holes for 1/8” cable 714485 2” x 2” 42” above surface Yes, 13 holes for 3/16” cable Part # Post Type 982703 Terminal 989177 Intermediate For stainless maintenance products see page 65.
54 | 360.323.5416 | STAINLESSCABLERAILING.COM ROUND & SQUARE WELDED DECK MOUNT POSTS These deck mount posts arrive with base plates welded to the bottom. Ideal for applications where welding is required by code or where customers want to cut down on installation time. Simply bolt the posts to your surface. Each assembly comes with a post cap and a cover plate. Some post caps are installed using epoxy, while others are welded like the base plate. FEATURES & BENEFITS HAWAII (SSR W/ FLAT CAP*) Part # Post Shape Height Post Type 713433 Round 36” Intermediate 713570 Round 42” Intermediate 713440 Round 36” Terminal 713587 Round 42” Terminal MAUI (SSR W/ RADIUS CAP*) *Specify if the posts will have fixed caps (for straight runs) or adjustable (for stairs). Use epoxy (p. 64) to install. **Welded to post prior to shipping. Mitre cutting and angled welding can be done for stairs upon request. ***Intended for St. Croix posts, since both the caps and base plates are welded to the posts prior to installation. Part # Post Shape Height Post Type 713655 Round 36” Intermediate 713730 Round 42” Intermediate 713662 Round 36” Terminal 713747 Round 42” Terminal • Base plates are welded to the posts for shorter installation time and a stronger, architectural hold • Many post cap options available. Caps are welded to the posts or installed using epoxy • Post attaches to the top of a surface for relatively simple installation • Naturally strong, corrosion-resistant material with a brushed finish • Passivated prior to shipping for long-lasting protection • Cover plates included with post assemblies • Posts are pre-drilled to reduce installation time and effort. Listings below are drilled for 1/8” cable, but 3/16” holes are also available. Specify hole size when ordering
STAINLESSCABLERAILING.COM | 360.323.5416 | 55 POSTS STAINLESS STEEL ST. JOHN (SSR W/ FLAT CAP*) ST. KITTS (SSR W/ RADIUS CAP*) ST. CROIX (SSR W/ LOW CAP**) SQUARE SPLIT COVER PLATES*** Part # Post Shape Height Post Type 712511 Square 36” Intermediate 712597 Square 42” Intermediate 712528 Square 36” Terminal 712603 Square 42” Terminal Part # Post Shape Height Post Type 712672 Square 36” Intermediate 712757 Square 42” Intermediate 712689 Square 36” Terminal 712764 Square 42” Terminal Part # Post Shape Height Post Type 712832 Square 36” Intermediate 712917 Square 42” Intermediate 712849 Square 36” Terminal 712924 Square 42” Terminal ROUND COVER PLATE Part # 010892 SQUARE COVER PLATES Part # Post Type 991866 Terminal 989184 Intermediate Part # Post Type 012421 Terminal 012414 Intermediate For stainless maintenance products see page 65. “The job was completed and I just want to tell you how much I appreciate your excellent service. I will definitely recommend you and your company to others who need help with their cable railings.”– Jeannine, Lahaina, HI
56 | 360.323.5416 | STAINLESSCABLERAILING.COM ROUND FASCIA / CORE MOUNT POSTS Fascia mount posts attach to the side of a deck or other surface. This installation method is particularly discreet, preserves your usable surface area, and creates the illusion of additional space. Our stainless steel posts are naturally strong and easily handle the tension of cable infill. The material is also corrosion-resistant, making it ideal for outdoor applications in marine environments. FEATURES & BENEFITS • Post attaches to the side of a surface to preserve your space • Requires fascia brackets to mount. Many bracket options available • Post caps can be attached using epoxy (sold separately, p.62) or can be ordered pre-welded to posts (for commercial applications, p.60) • Naturally strong, corrosion-resistant material with a brushed finish • Passivated prior to shipping for long-lasting protection Rectangular Fascia Brackets Use instead of Round Fascia Bracket on terminal post corners. (Allows for closer spacing, to maintain a 4” gap.) ESTIMATOR TIP TERMINAL (END POSTS) Part # Dimensions Final Rail Height Drilled 988774 2” Outer Diameter 36” above surface No, undrilled 988781 2” Outer Diameter 42” above surface No, undrilled 714393 2” Outer Diameter 36” above surface Yes, 11 holes for 1/8” cable 714409 2” Outer Diameter 36” above surface Yes, 11 holes for 3/16” cable 714416 2” Outer Diameter 42” above surface Yes, 13 holes for 1/8” cable 714423 2” Outer Diameter 42” above surface Yes, 13 holes for 3/16” cable
STAINLESSCABLERAILING.COM | 360.323.5416 | 57 POSTS STAINLESS STEEL INTERMEDIATE (IN-BETWEEN) INSTALLATION DETAIL Part # Type 732585 2-Hole 989733 4-Hole for Term. 732592 4-Hole for Int. RECTANGULAR BRACKETS CAPS (BOTTOM OF POST) Part # Dimensions Final Rail Height Drilled 988712 2” Outer Diameter 36” above surface No, undrilled 988729 2” Outer Diameter 42” above surface No, undrilled 714317 2” Outer Diameter 36” above surface Yes, 11 holes for 1/8” cable 714324 2” Outer Diameter 36” above surface Yes, 11 holes for 3/16” cable 714331 2” Outer Diameter 42” above surface Yes, 13 holes for 1/8” cable 714348 2” Outer Diameter 42” above surface Yes, 13 holes for 3/16” cable Part # Type 734756 Terminal 982185 Intermediate For stainless maintenance products see page 65.
58 | 360.323.5416 | STAINLESSCABLERAILING.COM SQUARE FASCIA / CORE MOUNT POSTS Fascia mount posts attach to the side of a deck or other surface. This installation method is particularly discreet, preserves your usable surface area, and creates the illusion of additional space. Our stainless steel posts are naturally strong and easily handle the tension of cable infill. The material is also corrosion-resistant, making it ideal for outdoor applications in marine environments. FEATURES & BENEFITS • Post attaches to the side of a surface to preserve your space • Mounts directly to fascia board using screws or fascia brackets • Post caps can be attached using epoxy (sold separately on p.63) or can be ordered pre-welded to posts (for commercial applications; see p.60) • Naturally strong, corrosion-resistant material with a brushed finish • Passivated prior to shipping for long-lasting protection Standoff Spacer Use when mounting to a deck with a drip edge. Stack multiple for larger drip edges. ESTIMATOR TIP TERMINAL (END POSTS) Part # Dimensions Final Rail Height Drilled 988170 2” x 2” 36” above surface No, undrilled 988187 2” x 2” 42” above surface No, undrilled 714539 2” x 2” 36” above surface Yes, 11 holes for 1/8” cable 714546 2” x 2” 36” above surface Yes, 11 holes for 3/16” cable 714577 2” x 2” 42” above surface Yes, 13 holes for 1/8” cable 714584 2” x 2” 42” above surface Yes, 13 holes for 3/16” cable
STAINLESSCABLERAILING.COM | 360.323.5416 | 59 POSTS INTERMEDIATE (IN-BETWEEN) INSTALLATION DETAIL STAINLESS STEEL Part # Dimensions Final Rail Height Drilled 988118 2” x 2” 36” above surface No, undrilled 988125 2” x 2” 42” above surface No, undrilled 714515 2” x 2” 36” above surface Yes, 11 holes for 1/8” cable 714522 2” x 2” 36” above surface Yes, 11 holes for 3/16” cable 714553 2” x 2” 42” above surface Yes, 13 holes for 1/8” cable 714560 2” x 2” 42” above surface Yes, 13 holes for 3/16” cable Part # Post Type 982222 Terminal 982215 Intermediate RECTANGULAR BRACKETS STANDOFF SPACER & PLATE CAPS (BOTTOM OF POST) Part # Post Type 732271 Terminal 732264 Intermediate Part # Type 732486 Spacer 731830 Plate For stainless maintenance products see page 65.
60 | 360.323.5416 | STAINLESSCABLERAILING.COM ROUND & SQUARE WELDED FASCIA & CORE POSTS These fascia mount posts are bundled with post caps. Some are welded to the posts prior to shipping, while others are attached using epoxy during installation. Ideal for applications where welding is required by code or where customers want to cut down on installation time. Fascia mounting brackets and hardware sold separately. See previous pages for more information and product offerings. FEATURES & BENEFITS OAHU (SSR W/ FLAT CAP*) Part # Post Shape Height Post Type 713815 Round 36” Intermediate 713891 Round 42” Intermediate 713822 Round 36” Terminal 713907 Round 42” Terminal KAUAI (SSR W/ RADIUS CAP*) *Specify if the posts will have fixed caps (for straight runs) or adjustable (for stairs). Use epoxy (p. 64) to install. **Welded to post prior to shipping. Mitre cutting and angled welding can be done for stairs upon request. Part # Post Shape Height Post Type 713976 Round 36” Intermediate 714058 Round 42” Intermediate 713983 Round 36” Terminal 714065 Round 42” Terminal • Many post cap options available. Caps are welded to the posts or installed using epoxy • Post attaches to the side of a surface to preserve your space • Mounts directly to fascia board using screws or fascia brackets • Naturally strong, corrosion-resistant material with a brushed satin-grain finish • Passivated prior to shipping for long-lasting protection • Posts are pre-drilled to reduce installation time and effort. Listings below are drilled for 1/8” cable, but 3/16” holes are also available. Specify hole size when ordering
STAINLESSCABLERAILING.COM | 360.323.5416 | 61 POSTS STAINLESS STEEL FASCIA BRACKETS, STANDOFF SPACERS AND BOTTOM CAPS FOR SQUARE POSTS See pages 57 KEY WEST (SSR W/ FLAT CAP*) SAN JUAN (SSR W/ RADIUS CAP*) CATALINA (SSR W/ LOW CAP**) Part # Post Shape Height Post Type 712993 Square 36” Intermediate 713075 Square 42” Intermediate 713006 Square 36” Terminal 713082 Square 42” Terminal Part # Post Shape Height Post Type 713150 Square 36” Intermediate 713235 Square 42” Intermediate 713167 Square 36” Terminal 713242 Square 42” Terminal Part # Post Shape Height Post Type 713273 Square 36” Intermediate 713358 Square 42” Intermediate 713280 Square 36” Terminal 713365 Square 42” Terminal For stainless maintenance products see page 65. “The stainless and cable railing system has a clean and beautiful look. We have used them on a few projects now. The system is easy to install and the customer service dept helpful.” – Andrea, New Paltz, NY
62 | 360.323.5416 | STAINLESSCABLERAILING.COM ROUND POST CAPS (CORNERS RADIUS) ROUND POST CAPS (CORNERS FLAT) ROUND POST CAPS (INLINE RADIUS) ROUND POST CAPS (INLINE FLAT) ROUND POST CAPS (STAIRS RADIUS) ROUND POST CAPS (STAIRS FLAT) POST CAPS FOR TOP RAIL MOUNTING (ROUND) These post caps connect your round stainless steel posts to your desired top rail. Radius caps mount our Stainless Round Top Rail, while flat caps mount our Stainless Flat Top Rail and Premium Wood Rails. Select one post cap per intermediate or terminal post. Attach to posts using epoxy (p.66) or welding. Attach to top rail using screws (p.64). We also offer coped collar caps (p.64) as a low-profile alternative for seamless connections in round stainless systems. Part # POST TYPE 733124 Terminal 731526 Intermediate Part # POST TYPE 733117 Terminal 731519 Intermediate Part # POST TYPE 982796 Terminal 731496 Intermediate Part # POST TYPE 734787 Terminal 731595 Intermediate Part # POST TYPE 733100 Terminal 731502 Intermediate Part # POST TYPE 982802 Terminal 731489 Intermediate
